Coriolis mass flowmeter for advanced process applications
- High accuracy (±0.05% flat), for cryogenic to HT media (-200…+400°C / -328…+752°F); maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
- SIL 2/3; CT: OIML R117, R137, MI-005, MI-002; API, AGA; hygienic certifications
- Flange: DN10…300 / ½…12", max. PN 160 / ASME Cl 1500
- 3 x 4…20 mA, HART®7, Modbus, FF, Profibus-PA/DP, PROFINET, EtherNet/IP™, Bluetooth®
|  |
Coriolis mass flowmeter for universal applications and process control
- Mass, density and volume flow of gases and liquids; maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
- Also certified for hygienic use
- Flange: DN15…100 / ½…4", max. PN100 / ASME Cl 600; many hygienic fittings
- 3 x 4…20 mA, HART®7, FF, Profibus-PA/DP, Modbus, PROFINET, EtherNet/IP™, Bluetooth®
|  |
Coriolis mass flowmeter for advanced process applications
- High accuracy (±0.1%), for viscous, aggressive or shear-sensitive media; maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
- CT: OIML R117, MI-005; API; hygienic certifications
- Flange: DN10…100 / ½…4", max. PN100 / ASME Cl 600; others
- 3 x 4…20 mA, HART®7, Modbus, FF, Profibus-PA/DP, PROFINET, EtherNet/IP™, Bluetooth®
|  |
Coriolis mass flowmeter for highest capacity bulk measurement
- For gases and liquids up to 4,600 t/h; maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
- CT: OIML R117, MI-005, MI-002; API and AGA compliant
- Flange: DN100…400 / 4…16", max. PN160 / ASME Cl 1500
- 3 x 4…20 mA, HART®7, Modbus, FF, Profibus-PA/DP, PROFINET, EtherNet/IP™, Bluetooth®
|  |
Coriolis mass flowmeter for low flow and dosing applications
- High accuracy (±0.1%) for gases and liquids >0.3 kg/h / 0.01 lb/min; maintains operation over a wide range of gas fractions and complex flow conditions (EGMTM)
- Standard pressure rating up to 300 bar / 4351 psi
- Flange: DN15 / 1/2"; also thread and clamp connections
- 3 x 4…20 mA, HART®7, Modbus, FF, Profibus-PA/DP, PROFINET, EtherNet/IP™, Bluetooth®
|  |
Coriolis mass flowmeter for advanced applications and process control
- Single straight tube for mass, density and volume flow of viscous, aggressive or shear-sensitive media
- Also certified for hygienic use
- Flange: DN10…100 / ½…4", max. PN100 / ASME Cl 600; others
- Integrated Modbus; optional EtherNet/IP™ interface
|  |
Coriolis mass flowmeter for low flow and dosing applications
- Mass, density and volume flow of liquids and gases (>0.3 kg/h / 0.01 lb/min)
- Standard pressure rating up to 300 bar / 4351 psi
- Flange: DN15 / ½"; thread, clamp, etc.
- Integrated Modbus; optional EtherNet/IP™ interface
|  |
Coriolis mass flowmeter for universal applications and process control
- For mass, density and volume flow of liquids and gases up to +130°C / +266°F
- Also certified for hygienic use
- Flange: DN15…100 / ½…4", max. PN100 / ASME Cl 600; many hygienic fittings
- Integrated Modbus; optional EtherNet/IP™ interface
|  |
