M&C TechGroup

SP2200-H/C/I/BB 230V

Gas sample probe type SP2200-H/C/I/BB. With external ceramic filter type S-2K150, filter porosity: 2µm, with electrically heated external filter 0-180°C adjustable by an incorporated thermostat, over temperature limiter with reset key at +30°C Tsetting and low temp. alarm with potential free status-alarm contact at -30°C below Tsetting. With calibration-, isolation- and blowback valve. Incl. weather protection shield with insulation. Power: 230V/50Hz, 800W. mounting flange: DN65 PN6B with thread G3/4″i. Sample gas OUT: 1/4″NPTi. Material: SS316, ceramic, Viton.

Application Areas: The SP2200-H sample probes are used for continuous extraction of gases from high dust loaden, high temperature or humid processes. They can be backflushed with a closed sample gas outlet.

SP2000-H320/S 230V

Sample Probe type SP2000-H320/S. With external ceramic filter type S-2K150, filter porosity: 2µm, filter element seal and lid seal out of graphite. with electrically heated external filter 0-320°C adjustable by an incorporated thermostat, over temperature limiter with reset key at +30°C Tsetting and low temp. alarm with potential free status-alarm contact at -30°C below Tsetting. incl. weather protection shield with insulation. mounting flange: DN65PN6B with thread G3/4″i, incl. flange gasket and screws. Pre-separator out of glass/Hastelloy with peristaltic pump SR25.1, mounted on a mounting plate out of aluminium, material: SS316, ceramic, graphit, glass, PVDF, PTFE, Hastelloy. Calibration gas connection: 6 mm tube with plug, sample outlet: GL18-8 with PVDF connector for tube DN4/6. Power: 230V/50Hz, 800W.

Application Areas: M&C has developed a special sampling technique for continuous gas sampling of waste gas in DENOX plants (SCR) where NH3 is added to the flue gas in order to reduce the NOX content. This new sampling technique has also proved to be suitable for processes with very high pollutant concentrations. In these applications, a big problem is the measurement of NOX, SO2 and O2-concentrations. With temperatures of <300°C, ammonium salts are produced due to the chemical reaction of NH3 and the SO2/SO3 in the flue gas. This salification is blocking up filters and sample lines in a short time. The special M&C gas sample probe SP2000-H320/S represents a good solution for these problems.

SP3100V/EX, ZONE 1

For sampling from zones with explosive gas, with stainless steel filter element outside, optional: ceramic filter element, heating, back purging, sample tubes and pre-filter.
