Krohne Magmeter

Electromagnetic flowmeters

For all applications with conductive liquids

  • From basic to demanding flow measurements, incl. custody transfer and safety-related applications (up to SIL 2/3)
  • Designs and liner materials for virtually any application – from potable water to extremely adhesive, abrasive and aggressive liquids
  • Large choice of nominal sizes up to DN3000 / 120"
  • Stock in Beverly, MA
  • Eliminate grounding rings with virtual reference

OPTIFLUX 4400

Electromagnetic flowmeter for safety instrumented systems (SIS) and high-accuracy requirements

  • Certified for safety applications up to SIL 2/3, with automated partial proof test capability for extended proof test intervals
  • Best-in-class diagnostic test interval incl. fault response time of only 2 minutes
  • SIL 2/3 up to DN600 / 24"; non-SIL up to DN2000 / 80" (larger on request)
  • Pulse, frequency, status, 4…20 mA, HART®7



OPTIFLUX 4300

Electromagnetic flowmeter for advanced process and custody transfer (CT) applications

  • High accuracy (±0.2%), certified for custody transfer
  • For low conductivity media (>1 μS/cm) and high solid contents (≤70%)
  • Flange: DN2.5…3000 / ⅒…120", max. PN40 / ASME Cl 600
  • 3 x 4…20 mA, HART®,Modbus, FF, Profibus-PA/DP, PROFINET

TIDALFLUX 2300

Electromagnetic flowmeter for applications with partially filled pipes

  • With integrated capacitive level measurement for flow measurement of water and wastewater (≥10% pipe fill level)
  • Accurate (±1%) and cost-saving alternative to open channel systems
  • Flange: DN200…1600 / 8…64"
  • 3 x 4…20 mA, pulse, HART®, Modbus, PROFINET

OPTIFLUX 5300

Electromagnetic flowmeter for advanced process and master meter applications

  • Highest accuracy (±0.15%), with ceramic tube for aggressive and abrasive liquids (≤70% solid content) up to +180°C / +356°F
  • CT: OIML R117, MI-005 etc.
  • Flange: DN15…300 / ½…12", max. PN40 / ASME Cl 300; Sandwich: DN2.5...100 / ⅒...4"
  • 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

OPTIFLUX 7300

Electromagnetic flowmeter for low conductivity liquids (≥0.05 μS/cm)

  • Ceramic tube with non-wetted electrodes for extremely adhesive and abrasive media
  • Hygienic and vacuum resistant
  • Flange or wafer/sandwich version: DN25…100 / 1…4", max. PN40 / ASME Cl:300
  • 3 x 4…20 mA, HART®, Modbus, FF, Profibus-PA/DP, PROFINET

Eliminate Grouding Rings with Virtual reference

Virtual reference is a propriety design offered by Krohne that uses an internal reference rather than using grounding rings.  This allows for cleaner signal and less maintence keeping grounding rings clean from corrosion.  This option can even save money when using more expensive Hast-C grounding rings.

Read White Paper
